vrf建立dmvpn邻居.note

# 要求：DMVPN使用VRF建立连接
## 关键命令：tunnel vrf EXTERNAL

# R5：
## 定义VRF、接口关联：
vrf definition EXTERNAL
 rd 5:1
 address-family ipv4
 address-family ipv6

interface GigabitEthernet0/0
 vrf forwarding EXTERNAL

## 配置 DMVPN：
interface Tunnel0
 tunnel vrf EXTERNAL
 tunnel mode gre multipoint
 tunnel source GigabitEthernet0/0
 ip address 100.0.1.5 255.255.255.0
 ipv6 enable
 ipv6 address 2001:100:0:1::5/64
 ip nhrp network-id 1
 ip nhrp authentication DMVPN
 ip nhrp redirect

# R1~R4：
## 定义VRF、接口关联：
vrf definition EXTERNAL
 rd 1:1
 # rd 2:1
 # rd ...
 address-family ipv4
 address-family ipv6

interface GigabitEthernet0/0
 vrf forwarding EXTERNAL

## 配置 DMVPN：
interface Tunnel0
 tunnel vrf EXTERNAL
 tunnel mode gre multipoint
 tunnel source GigabitEthernet0/0
 ip address 100.0.1.1 255.255.255.0
 ipv6 enable
 ipv6 address 2001:100:0:1::1/64
 ip nhrp network-id 1
 ip nhrp authentication DMVPN
 ip nhrp nhs 100.0.1.5 nbma 4.4.4.5 multicast
 ipv6 nhrp authentication DMVPN
 ipv6 nhrp network-id 1
 ipv6 nhrp nhs 2001:100:0:1::5 nbma 4.4.4.5 multicast
